Stand-alone DVR Instruction Manual
70
[Fig. 6-49 Copy Start time and Channel Selection window]
① All channels, HOUR selection button.
Click the arrow button in the upper left corner as shown in [Fig. 6-49] to set the full extent of
the recording and all the channels simultaneously.
② HOUR selection button
Select the start time to copy by clicking the mouse on HOUR (0-23: in the military hour).
Thereafter the extent of the recording will be saved on.
③ Channel selection button
Some channels can be selected by clicking the mouse on the corresponding channels.
By using the Copy Start/End set-up buttons:
The time and date can also set on the Copy Start/End set-up buttons window (See [Fig. 6-50]).
▫ Select the values (year/month/date and hour/minute/second) by clicking the mouse, change
the values with the mouse’s wheel and click the mouse again on the changed values to
complete as shown in [Fig. 6-50].
② HOUR selection button
① All channels, HOUR selection
③ channel selection
