INSTALLATION INSTRUCTIONS
9527 Instructions 6-18-12 F series-1 (1).doc 4 of 38
Section 1: Camera Mount Preparation continued
9. Drill a pilot hole for the camera mount. Using
a 1¾ inch hole saw, cut the camera harness
opening. Trial fit camera mount and file
opening as necessary (Figure 5).
Figure 5
10. Apply Z-tech to camera harness opening.
