INSTALLATION INSTRUCTIONS
9527 Ford Flex Instructions 7-27-12.doc 8 of 18
Section 4: Mirror Removal
37. Start the vehicle and note location of
compass display. Remove the connector from
the inside rearview mirror (Figure 15).
Figure 15
38. If the compass display on the dash shows
(- -) the compass module must be relocated.
This operation is described in Section 6.
39. Verify mirror mount retention method. If
the vehicle mirror is retained with a screw, use a
T20 Torx driver to remove the screw that
attaches the existing rear view mirror to the
windshield (Figure 16).
Figure 16
40. If the vehicle mirror is retained with a clip,
use Mirror Removal Tool # OTC8200 available
from Brandmotion.com or Ford dealers to
release the mirror (Figure 17).
Figure 17
CAUTION: Removing the mirror from
can cause damage to the windshield.
It is highly recommended to
contact either a Ford dealership or
a automotive glass replacement
company to perform this task.
41. Slide the mirror upward to remove and
set aside.
Mirror Removal Tool
# OTC8200
