Appendix
B
Accessories
Installation, Maintenance,
and Replacement Kits Accessories available for installing linear stages, replacing items, and performing
maintenance at regular intervals are listed in the tables that follow.
Topic Page
Installation, Maintenance, and Replacement Kits 83
Table 12 - Accessories Common to Ball Screw and Direct Drive Linear Stages
Description Catalog Number Comments
Grease Pump Maintenance Kit MPAS-GPUMP Includes grease pump, one grease cartridge, and all necessary tips.
Grease Cartridge MPAS-CART Refill cartridge for grease pump.
Toe Clamp Installation Kit MPAS-TOE 10 toe clamps per package
Tee Nut Installation Kit MPAS-6-TNUT 10 Tee nuts per package
MPAS-8-TNUT
MPAS-9-TNUT
Table 13 - Accessories for Ball Screw Linear Stages
Description Catalog Number Comments
Couplers MPAS-6-COUP
MPAS-8-COUP
MPAS-9-COUP
Rotary Servo Motors MPLS-A210E-V-x246 230V non-brake motor for 5 mm/rev ball screw
MPLS-A210E-V-x247 230V brake motor for 5 mm/rev ball screw
MPLS-B210E-V-x248 460V non-brake motor for 5 mm/rev ball screw
MPLS-B210E-V-x249 460V brake motor for 5 mm/rev ball screw
MPLS-A220H-V-x250 230V non-brake motor for 20 mm/rev ball screw
MPLS-A220H-V-x251 230V brake motor for 20 mm/rev ball screw
MPLS-B220H-V-x252 460V non-brake motor for 20 mm/rev ball screw
MPLS-B220H-V-x253 460V brake motor for 20 mm/rev ball screw
Strip Seal Replacement Kits MPAS-6xxx1-SEAL xxx = cm stroke:
012, 018, 024, 030, 036, 042, 054, or 066
MPAS-8xxx1-SEAL xxx = cm stroke:
012, 018, 024, 030, 036, 042, 054, 066, 078, 090, or 102
MPAS-9xxx1-SEAL xxx = cm stroke:
012, 018, 024, 030, 036, 042, 054, 066, 078, 090, or 102
