54 Rockwell Automation Publication MP-UM001D-EN-P - September 2013
Chapter 6 Configuration Guidelines
Table 7 - Direct Drive Linear Stage Distance Unit Settings
Table 6 - Scaling Parameters Values
User Unit Scaling Parameters (1) Distance Units for Ball Screw Linear Stages
Millimeters Inches
MPAS-xxxxxx-V05xxA MPAS-xxxxxx-V20xxA MPAS-xxxxxx-V05xxA MPAS-xxxxxx-V20xxA
Velocity Label mm/s mm/s in./s in./s
Velocity Scale 26214.4 6553.6 665845.76 166461.44
Position Label mm mm in. in.
Position Scale 26214.4 6553.6 665845.76 166461.44
Acceleration Label mm/s/s mm/s/s in./s/s in./s/s
Acceleration Scale 26214.4 6553.6 665845.76 166461.44
(1) User units are determined by the screw lead of the linear stage. The screw lead is defined in linear units of travel per revolution. For example, the travel per revolution of an MPAS-xxxxxx-V05xxA is 5 mm/
rev and that of an MPAS-xxxxxx-V20xxA is 20 mm/rev. MP-Series linear stages with a ball screw use a feedback device that provides 128 sin/cos cycles per revolution of the motor. The Ultra3000 drive
interpolates this signal by an additional 1024, causing the maximum count per internal motor revolution of the linear stage to be 131,072 counts/rev.
User Unit Scaling Parameters Distance Units
Millimeters Inches
Velocity Label mm/s in./s
Velocity Scale 200 5080
Position Label mm in.
Position Scale 200 5080
Acceleration Label mm/s/s in./s/s
Acceleration Scale 200 5080
