Chapter 4
Parameters and Function Codes
P313
Digital Output #3 Logic
1: Inverting
0: Non-Inverting
0
ON
0
1
P314
Digital Output #3 Bit Selection (0...15)
3
ON
0
15
P315
Digital Output #3 Delay (ms)
0
ON
0
32767
P316
Digital Output #4 Memory Address
99
ON
0
500
P317
Digital Output #4 Logic
1: Inverting
0: Non-Inverting
0
ON
0
1
P318
Digital Output #4 Bit Selection (0...15)
4
ON
0
15
P319
Digital Output #4 Delay (ms)
0
ON
0
32767
P320
Digital Output #5 Memory Address
99
ON
0
500
P321
Digital Output #5 Logic
1: Inverting
0: Non-Inverting
0
ON
0
1
P322
Digital Output #5 Bit Selection (0...15)
5
ON
0
15
P323
Digital Output #5 Delay (ms)
0
ON
0
32767
P324
Digital Output #6 Memory Address
99
ON
0
500
P325
Digital Output #6 Logic
1: Inverting
0: Non-Inverting
0
ON
0
1
P326
Digital Output #6 Bit Selection (0...15)
6
ON
0
15
P327
Digital Output #6 Delay (ms)
0
ON
0
32767
P328
Digital Output #7 Memory Address
99
ON
0
500
P329
Digital Output #7 Logic
1: Inverting
0: Non-Inverting
0
ON
0
1
P330
Digital Output #7 Bit Selection (0...15)
7
ON
0
15
P331
Digital Output #7 Delay (ms)
0
ON
0
32767
P332
Analog Output #1 Memory Address
252
ON
0
500
P333
Analog Output #1 Filter Time (ms)
1000
ON
0
32767
P334
Analog Output #1 Offset
0
ON
-100
100
P335
Analog Output #1 Scaling Factor
100
ON
0
199.99
P336
Analog Output #2 Memory Address
206
ON
0
500
P337
Analog Output #2 Filter Time (ms)
1000
ON
0
32767
P338
Analog Output #2 Offset
0
ON
-100
100
P339
Analog Output #2 Scaling Factor
100
ON
0
199.99
P340
Analog Output #3 Memory Address
0
ON
0
500
P341
Analog Output #3 Filter Time (ms)
1000
ON
0
32767
P342
Analog Output #3 Offset
0
ON
-100
100
P343
Analog Output #3 Scaling Factor
100
ON
0
199.99
P344
Analog Output #4 Memory Address
0
ON
0
500
P345
Analog Output #4 Filter Time (ms)
1000
ON
0
32767
Parameter
Number
Description
Default
Value
Modify
Root
Lower
Limit
Upper
Limit
