Rockwell Automation Publication 6000-UM001B-EN-P - October 2014 57
Chapter
4
Parameters and Function Codes
P Parameters
Parameter
Number Description Default
Value Modify
Root Lower
Limit Upper
Limit
P004 Command Source
0: Communication Port
1: Other Sources 0 OFF 0 1
P005 Restore Factory Settings
40: User Level
30: Setup Level
50: R&D Level 0 OFF 0 50
P007 Number Of Power Cells Per Phase 9 ON 0 9
P008 Motor Rotation Direction Under Local Control
1: Forward
0: Reverse 1 OFF 0 1
P009 Motor Rotation Direction Command Selection:
0: Local
1: DCS 0 OFF 0 1
P010 Power Cell Fault Mask 32767 ON 0 32767
P017 Number Of Motor Pole Pairs 2 OFF 0 100
P018 Enable Flying Start With Encoder 0 OFF 0 1
P019 Encoder Resolution 1024 OFF 0 4096
P020 Mask Bit For System Fault 32767 ON 0 32767
P021 Mask Bit For System Warning 32767 ON 0 32767
P022 Mask Bit For Logic Fault A 32767 ON 0 32767
P023 Mask Bit For Logic Fault B 32767 ON 0 32767
P024 Stop Method
0: Ramp Down
1: Coast Stop 0 ON 0 1
P025 Flux Reduction Enable 0 ON 0 1
P026 Power Angle Threshold For Flux Reduction 0 ON 0 180
P027 Time For Flux Reducing 5000 ON 0 32767
P028 Flux Reduction Ratio 70 ON 0 100
P029 Power Angle Threshold For Flux Restore 0 ON 0 180
P040 Safe Start Condition
0: Zero Frequency Command Required
1: Frequency Command Allowed 1 OFF 0 1
P089 Skip Frequency Enable
0: Disable
1: Enable 0 ON 0 1
