28 Rockwell Automation Publication 6000-UM001B-EN-P - October 2014
Chapter 2 Drive System Layout
Table 1 - Power Module Ratings
Hall Effect Current Sensors (HECs)
The Hall Effect Current Sensors are current transformers capable of measuring
current throughout the output frequency range of the drive. They monitor the
current waveform in each of the phases going to the motor and provide feedback
to the control system.
Top-mounted Main Cooling Fan(s)
The Top-mounted Cooling Fans ensure reliable cooling of the Power Modules.
They draw cool air in through the vents in the Power Module Cabinet doors,
through the Power Modules, and exhaust the heated air out through the top of
the cabinet.
Catalog Number Spare Part Number Current Rating (Amps)
TPUxx/030-AC3 HTPUXX/030-AC3-R 30
TPUxx/040-AC3 HTPUXX/040-AC3-R 40
TPUxx/050-AC3 HTPUXX/050-AC3-R 50
TPUxx/060-AC3 HTPUXX/060-AC3-R 60
TPUxx/075-AC3 HTPUXX/075-AC3-R 75
TPUxx/080-AC3 HTPUXX/080-AC3-R 80
TPUxx/100-AC3 HTPUXX/100-AC3-R 100
TPUxx/120-AC3 HTPUXX/120-AC3-R 120
TPUxx/150-AC3 HTPUXX/150-AC3-R 150
TPUxx/180-AC3 HTPUXX/180-AC3-R 180
TPUxx/200-AC3 HTPUXX/200-AC3-R 200
TPUxx/300-AC3 HTPUXX/300-AC3-R 300
TPUxx/380-AC3 HTPUXX/380-AC3-R 380
TPUxx/420-AC3 HTPUXX/420-AC3-R 420
