Rockwell Automation Publication 6000-UM001B-EN-P - October 2014 119
Appendix
A
Technical Specifications
Description
Power Rating Range @ 3 kV motor voltage 320…1600 kW
Power Rating Range @ 3.3 kV motor voltage 360…1720 kW
Power Rating Range @ 6 kV motor voltage 200…3360 kW
Power Rating Range @ 6.6 kV motor voltage 220…3720 kW
Power Rating Range @ 10 kV motor voltage 200…5600 kW
Motor Type Induction (asynchronous) motors
Input Voltage Rating 3 kV, 3.3 kV, 6 kV, 6.6 kV, 10 kV, 11 kV
Input Voltage Tolerance ±10% of Nominal
Input Voltage Sag -20% of Nominal, duration – 60 seconds
Input Frequency 50/60 Hz, ±5%
Input Impedance Device Multiphase Isolation Transformer
Output Voltage 0…3000V, 0…3300V, 0…6000V, 0…6600V, 0…10,000V
Rectifier Configurations 18 pulse (3 kV, 3.3 kV), 36 pulse (6 kV, 6.6 kV), 54 pulse (10 kV, 11 kV)
Inverter Configuration Pulse Width Modulated (PWM) power modules
Power Semiconductors Diodes (rectifier), IGBTs (inverter)
Output Current THD (1st…49th) < 5%
Output Waveform to Motor Near Sinusoidal Current / Voltage
Medium Voltage Isolation Fiber Optic
Control Method Volts per hertz
Output Frequency Range 0.5…75 Hz
Acceleration/Deceleration time 0...3276 seconds
Flying Start Capability Yes
Service Duty Rating 120% Overload for 1 min every 10 min
Input Power Factor >.95
VFD Efficiency (1) >96.5%
VFD Noise Level < 80 dB
Operator Interface 7 in. WinCE Color Touchscreen
Languages English, Chinese
Control Power 120V 60 Hz, 240V 60 Hz, 110V 50 Hz, or 220V 50 Hz (3 kVA)
External Input Ratings 24V DC
External Output Ratings 240V AC/2 A
Analog Inputs (Optional) Four non-isolated, 4…20 mA or 0…10V DC (two spare)
Analog Outputs (Optional) Two isolated: 4…20 mA, two isolated: 0…5V DC (spare)
Communications Protocols (Optional) RS232/422/485, Modbus, Modbus Plus, Profibus DP, EtherNet I/P
Enclosure IP31 (standard), IP42 (optional)
Structure Finish Epoxy Powder - Paint
Exterior Sandtex Light Grey (RAL 7038) - Black (RAL 8022)
Internal - Control Sub Plates - High Gloss White (RAL 9003)
Corrosion Protection Unpainted Parts (Zinc Plated / Bronze Chromate)
Ambient Temperature (Operating) 0…40 °C (standard), 0…50 °C (optional with derating)
Ambient Temperature (Storage) -25…55 °C
Relative Humidity Max. 95% non-condensing
Altitude 0…1000 m (standard)
1001…3000 m (optional)
(1) Average for Product Portfolio.
