Installing the MessageView Terminal

Publication 2706–816

4. Plug the removeable terminal block into the Terminal Power Port.

ATTENTION: Explosion Hazard – Do not connect
or disconnect equipment while circuit is live unless
area is known to be non-hazardous.

ATTENTION: Risque d’explosion - Ne pas
brancher ou debrancher tant que le circuit est sous
tension, a moins qu’il ne s’agisse d’un emplacement
non dangereux.

ATTENTION: Do not apply power to the terminal
until all wiring connections have been made.
Failure to do so may result in electrical shock.

5. Apply 24V DC power to the terminal.
