Specifications A–2
Publication 2706-816
VFD Display
Size (all terminals): inches 1.06 (H) x 4.27 (W)
26.9 (H) x 108.5 (W)
mm
Pixels
C a acte s
26.9 (H) x 108.5 (W)
128 x 32 dot matrix
Characters
Quarter Size
Hal
i e
21 x 4 lines
lines Half Size
Full Size 10 x 2 lines
7 x 1 line
Graphic Symbols 5 x 2 lines
Communications
Remote I/O
Baud Rate/Distance 57.6K/10,000 feet (2800 meters)
115.2K/5,000 feet (1400 meters)
230.4K/2,500 feet (700 meters)
RS-232 Point-to-Point (PC Link)
Baud Rate/Distance 19.2K/50 feet (6.1 meters)
Environment
Ambient Temperature
Operating 0 to 55 C (32 to 131 F)
Storage -40 to 85 C (-24 to 185 F)
Relative Humidity (Non-Condensing) 5 to 95%
Shock and Vibration
Impulse Shock (Operating/Non-operating) 30G/50G
Vibration (Operating) 10 to 57Hz (0.012 in / 0.3 mm)
58 to 150Hz (2G)
Battery/Fuse (to be replaced by an
authorized Allen-Bradley Field Service
Representative)
Battery Module Replacement Kit Catalog No. 2706-NB
Fuse Replacement Series 239 2.0 Amp Slo-Blo
Type GMC 2.0 Amp Time-Lag
Certifications
UL Listed for ordinary and hazardous
locations (Class I Division 2 Groups A,B,C,D)
Temperature Code T5
CSA certified
European Union Directive Electromagnetic Compatibility Directive
(89/336/EEC)
EN 50082-2 – 1995
Generic Immunity Standard -
Industrial Environment
EN 50081-2 – 1993
Generic Emission Standard -
Industrial Environment
