3–9 Front Panel Editor
Publication 2706–816
4. Press Ack to exit to the FPE menu.
You can choose when and how the values in the logic controller are
set when power to the terminal is applied, power is restored or the
terminal is reset:
1. Highlight Preset Operations and press the Enter key to
display the Preset Operations submenu.
Send Values At
Power-Up
Values at Power-Up
Port Power-Up
2. Use the up or down arrow keys to scroll through the
Preset Operations setup options.
3. Press the Enter key to access the submenu for a selected
option.
4. Use the up or down arrow keys to highlight an option.
5. Press the Enter key to select and save the highlighted option.
Or press the Ack key to exit without changing the option.
6. Press the Ack key twice to return to the FPE menu.
Send Values At Power–Up
When the terminal is powered up, or is reset after an application has
been running, values may be sent to the PLC or other logic controller
for each variable.
To view or edit the Send Values at Power-Up option:
1. Select Send Values At Power-Up and press the Enter key to
display the setting.
Send Values At
Power-Up
Enabled
Note: This option is always disabled for ASCII Trigger or Slave
Device MessageView terminal configurations (2706-M1D,
-M1N, -M1F).
Preset Operations
