Installing the Monitor Chapter 2
Panel Mounting The monitors install directly into a panel with mounting clips. The number of
clips varies by model.
Mounting Adapters
Optional mounting adapters are available to mount a monitor into the existing
panel cutout of an older monitor.
Required Tools
You need panel cutout tools and a #2 Phillips torque screwdriver.
Panel Cutout Dimensions
This table lists the panel cutout dimensions for each monitor. Use the full-size
template shipped with each monitor to mark the cutout dimensions.
Table 4 - Mounting Clips
Monitor Mounting Clips
1200M, 1500M, and 1700M aluminum bezel 10
1700M stainless steel bezel 12
1900M 14
Table 5 - Panel Mounting Accessories
Cat. No. Description
6189V-MCLPS3 Replacement Mounting Clips (14)
Table 6 - Panel Mounting Adapters
Cat. No. Description
6189V-MMA12 Panel adapter for converting 6185-B to 1200M
6189V-MMA15 Panel adapter for converting 6185-C, 6185-F, and 6185-H to 1500M
6189V-MMA17 Panel adapter for converting 6185-D and 6185-J to 1700M
Table 7 - Panel Cutout Dimensions
Monitor Model Cutout Dimensions, approx (H x W)
1200M (6186M-12) 238.0 x 318.0 mm (9.37 x 12.51 in.)
1500M (6186M-15) 285.6 x 386.6 mm (11.24 x 15.22 in.)
1700M (6186M-17) 329.5 x 424.0 mm (12.97 x 16.69 in.)
1900M (6186M-19) 363.5 x 449.6 mm (14.31 x 17.70 in.)
