Publication 2707-PM002B-EN-P
13-2 MicroView Function Key Builder
Auto Return
Auto return function keys return to the initial display after the linked
screen is executed. For example, assume that an application is
displaying screen #6 and an auto return function key F2 is linked to a
recipe screen #10. When F2 is pressed, the recipe screen #10 is
displayed. After the operator downloads a new recipe on screen #10,
the initial screen #6 will be again displayed.
The following table describes when the return to the initial screen
occurs.
Continue
Continue function keys do not return to the initial display but remain
at the linked screen. For example, assume that an application is
displaying screen #3 and a continue function key F1 is linked to a data
entry screen #5. When F1 is pressed, the data entry screen #5 is
displayed. The application continues from screen #5.
Function Key Linked To: Returns to Initial Screen After:
Data Display Screen [ ], [PREV] or [NEXT] keys are pressed
Data Entry Screen A value is entered or
[PREV] or [NEXT] keys are pressed *
Recipe Screen Recipe data is downloaded or
[PREV], or [NEXT] keys are pressed *
* [PREV] and [NEXT] abort the operation.
