Appendix
C
MicroLogix Mnemonics in DPS
The MicroView supports all MicroLogix mnemonics for logical
addressing to the sub-element or bit level. The following table
defines the default text for bit display fields when a bit display screen
is specified.
In MicroView DPS these fields can be edited and may contain any text
up to 16 characters. Default text is only applicable to mnemonic bit
sub-elements where there is a corresponding definition of the bit 0/1
state.
File Type Bit
Sub-Element 0 State
Default Text 1 State
Default Text
O (Output) -
I (Input) -
S (Status) -
B (Bit) -
T (Timer) .EN ENABLED
.TT TIMING
.DN DONE
HSC
(High Speed Counter)
.CU UP COUNTER
.CD DOWN COUNTER
.DN DONE
.OV OVERFLOW
.UN UNDERFLOW
.UA UPDATE
ACCUMULATOR
.HP HIGH PRESET
.LP LOW PRESET
.IV INTERRUPT
OVERFLOW
.IN INTERRUPT
UNDERFLOW
.IH INTERRUPT HIIGH
PRESET
.IIL INTERRUPT LOW
PRESET
