Publication 2707-PM002B-EN-P
MicroLogix Data Formats D-3
16 Bit BCD
This data format displays a 16 bit register address as a 4 digit Binary
Coded Decimal value.
16 Bit HEX (Hexadecimal)
This data format displays two consecutive 16 bit register addresses as
a 32 bit Hex value. It uses a memory register plus the next higher
register to form the 32 bit address.
TIP
The range for the 16 bit BCD selection is 0 to +9999.
This data format may also be scaled to different
engineering units.
Digit 1 Digit 2 Digit 3 Digit 4
Bit
16 Bit
13 Bit
12 9
Bit
8
Bit
5
Bit
4
Bit
1
Bit
Range = 0 to +9999
TIP
The range for the 32 bit HEX value is 0 to FFFFFFFF.
This format can’t be scaled to different engineering
units. Use this data format for display-only
(non-entry) operations.
Digit 1 Digit 2 Digit 3 Digit 4
Bit
16 Bit
13 Bit
12 9
Bit
8
Bit
5
Bit
4
Bit
1
Bit
Range = 0 to FFFF
