Publication 2707-PM002B-EN-P
3-8 Designing Microview Applications
Designing an Application Use the application design worksheets to layout a logical sequence of
screens. Make copies of the worksheets as needed. On each
worksheet, list the screen numbers, type of screens, register numbers,
etc.
Use the screen worksheets to define screen text and layout. Make
copies of the screen worksheets and write out each application
screen.
Before you design an application, become familiar with the types of
screens and how they function. To assist you, a sample application is
provided in this chapter. In addition, you should become familiar with
the controller files and data type supported for each operator module
type and selected protocol (see previous section). When register
information is required, this manual lists the applicable data formats
(such as ASCII or 16 Bit Hex) for each controller file type.
Application Worksheet
MicroView
Screen Worksheets
1 P U M P 2 L E V E L
P U M P
3 0 P
P R S S U R E E
0 S I
Screen # 1
Screen # 2
