Publication 6181P-UM001G-EN-P - July 2008

57

Appendix

A

Specifications

Display

Type

Active Matrix Color TFT

Touchscreen (optional)

Resistive antiglare

Display size
1200P
1500P
1700P

12.1 in.
15 in.
17 in.

Display area (WxH)
1200P
1500P
1700P

246 x 185 mm (9.7 x 7.3 in.)
305 x 229 mm (12 x 9 in.)
338 x 270 mm (13.3 x 10.7 in.)

Resolution, native
1200P
1500P
1700P

800 x 600, 256K colors
1024 x 768, 256K colors
1280 x 1024, 16.7M colors

Response time

15 ms (typical)

Mechanical

Weight
1200P
1500P
1700P

9.2 kg (21 lb)
10 kg (23 lb)
12.6 kg (28 lb)

Dimensions, overall (HxWxD)
1200P
1500P
1700P

279 x 349 x 176 mm (10.99 x 13.75 x 6.93 in.)
309 x 410 x 109 mm (12.17 x 16.14 x 4.29 in.)
356 x 452 x 110 mm (14.02 x 17.80 x 4.32 in.)

Cutout dimensions (HxW)
1200P
1500P
1700P

254 x 324 mm (10.00 x 12.76 in.)
285 x 386.6 mm (11.24 x 15.22 in.)
329.5 x 424 mm (12.97 x 16.69 in.)

Environmental

Temperature, operating

0…50 °C (32…122 °F)

Temperature, storage

-20…60 °C (-4…40 °F)

Relative humidity

10…90% without condensation

Shock, operating

15 g (1/2 sine, 11ms)

(1)(2)

(1)

Applies to panel mounted computers only.

(2)

The floppy disk drive and optical disc drive are considered maintenance devices. You should not operate
computers with these devices in environments with the shock and vibration levels listed.

Shock, nonoperating

30 g (1/2 sine, 11 ms)

(1)

Vibration, operating

Computers without solid state drive
Computers with solid state drive

1.0 g peak (10…500 Hz)

(1)(2)

1.5 g peak (10…500 Hz)

(1)

Vibration, non-operating

2.0 g peak (10…500 Hz)

(1)

Enclosure ratings

NEMA Type 1, 12, 4, IP66
NEMA Type 4X - stainless steel units only
