Bench or tabletop mounting – Rockwell Automation 6181P-xxxx Integrated Display Computers, Series A to D User Manual
Page 21

Publication 6181P-UM001G-EN-P - July 2008
21
Installation Chapter 2
6. Gradually tighten the clips, one at a time, around the bezel by
using the specified sequence.
The sequence begins with the center clips and continues to the
corner clips. Repeat this process at least three times until the
clips are hand-tight and the gasket is compressed uniformly
against the panel.
7. Tighten the mounting clips to a torque of 1.4 Nm (12 lb-in) by
using the sequence in step 6.
Do not overtighten.
Bench or Tabletop
Mounting
You can mount the 1500P or 1700P computer on a benchtop or
tabletop arm by using an optional adapter. The back of the computer
has four mounting points that are VESA 100 mm standard.
ATTENTION
Tighten the mounting clips to the specified torque to provide a
proper seal and prevent damage to the product. Rockwell
Automation assumes no responsibility for water or chemical
damage to the product or other equipment within the enclosure
because of improper installation.
1
10
9
2
7
8
5
4
3
6
Torque Sequence
Cat. No.
Description
6189V-MBA
Bench/tabletop adapter for 1500P and 1700P
