Bottom view – Rockwell Automation 6181P-xxxx Integrated Display Computers, Series A to D User Manual
Page 13
Publication 6181P-UM001G-EN-P - July 2008
13
System Features Chapter 1
Bottom View
Ethernet 10/100 Connector (RJ45)
2 USB Ports
COM4
PCI Expansion Slot
Compact Flash Expansion Slot
COM2
COM1
PS/2 Keyboard Port
DC Power Input
Power Switch
Printer
VGA Port
1200P
PS/2 Mouse Port
Reset
Button
Ethernet Connector (RJ45)
2 USB Ports
COM4
PCI Expansion Slot
Compact Flash Expansion Slot
COM2
COM1
PS/2 Mouse Port
AC Power Input
Power Switch
Printer 2
Printer 1
VGA Port
1500P and 1700P Series A
1500P and 1700P Series B
AC Power Input
Power Switch
COM4
COM2
COM1
Keyboard/Pointing Device Ports
PCI Expansion Slot
Printer
VGA Port
Compact Flash Expansion Slot
2 USB Ports
Ethernet Connector (RJ45)
PS/2 Keyboard Port
Reset
Button
