Replace the floppy drive (1500p and 1700p), Remove the floppy disk drive – Rockwell Automation 6181P-xxxx Integrated Display Computers, Series A to D User Manual
Page 40

40
Publication 6181P-UM001G-EN-P - July 2008
Chapter 4 Replace System Components
Replace the Floppy Drive
(1500P and 1700P)
Follow these precautions when working with the floppy drive.
•
Do not touch internal components unnecessarily.
•
Always handle the floppy drive by its metal frame.
•
Store the floppy drive in an anti-static bag when it is not
installed.
•
Never disconnect or install a floppy drive with the power on.
Remove the Floppy Disk Drive
Follow these steps to remove the floppy disk drive.
1. Disconnect power from the computer.
2. Remove the back cover.
3. Remove the hard drive.
Do not disconnect the HDD cables.
ATTENTION
Failure to follow proper safety precautions could result in
severe electrical shock and/or damage to the computer.
ATTENTION
Mechanical shock will damage a floppy drive. Do not drop or
bump the drive.
IMPORTANT
Note the location and orientation of all cables before you
remove the existing power supply and cabling, so that you can
reattach them correctly.
