Installation Chapter 2

Product Dimensions

Product dimensions for each version of the computer are given in
Dimensions are mm (in.).

1200P Integrated Display Computer

1200P Non-Display Computer

349 [13.75]

279 [10

.99]

175.9 [6.93]

281 [11.079]

251

[9.89]

320 [12.60]

8.00 [0.31]

317.5 [12.51]

240 [9.46]

144.9 [5.70]

2 (.078)

281 [11.079]

190.5 [7.5

1]

343 [13.51]

239.1 [9.4

1]
