Preface P–2
Publication 2711-6.2
The following conventions are used in this guide.
•
PanelBuilder refers to the PanelBuilder Configuration Software.
•
Terminal refers to a PanelView Operator Terminal.
•
Windows refers to Microsoft Windows versions 3.1 (or higher),
or Windows 95.
•
Keys on the keyboard appear in small capital letters. For
example, the Ctrl key appears as
CTRL in the text, the Alt key as
ALT, and so on.
•
When keys are to be pressed in combination, you’ll see them
connected by a +. For example,
ALT+F4 means hold down the ALT
key while you press F4.
•
Bold text precedes all procedures.
To open an application file:
•
A solid right cursor in the left margin indicates a tip or hint.
Anchor point is the handle opposite the handle you choose. The
anchor point doesn’t move when sizing objects.
The following table lists other publications related to the
PanelBuilder Software and the PanelView Operator Terminals.
Publication Title Publication No.
PanelBuilder Software User Manual 2711-6.0
PanelView Terminal User Manual 2711-6.1
PanelView File Transfer Utility 2711-805
For information on your PLC or SLC controller, the Advanced
Programming Software, or the 6200 Series Programming Software,
refer to the appropriate manuals.
For information on window operations, refer to your Windows user
guide.
Conventions
"
Related Publications
