Connect to a network – Rockwell Automation 6189V-xxxx Non-display Industrial Computers User Manual User Manual
Page 30

30
Rockwell Automation Publication 6177R-UM002D-EN-P - October 2014
Chapter 2
Installation
Connect to a Network
The computers have two 1 GB LAN ports that connect to an Ethernet network
by using CAT5 or CAT5E twisted-pair Ethernet cable with RJ45 connectors. See
starting on
for where the LAN ports are on each
computer model.
IMPORTANT
To help prevent performance degradation of Ethernet communication, do not
subject the computer or cables to extreme radiation or conducted
high-frequency noise.
In industrial environments, proper cable routing and power conditioning are
required for Ethernet communication. We recommend that you route all
Ethernet cabling through dedicated metal conduits. For improved performance
reliability, install ferrite bead filters at the cable ends.
