Chapter 4
Getting Started/Using the Security Levels
4 – 9
The USER-PAK option allows the ADMINISTRATOR to disable security
(that is, remove the password requirement) for entry into the setup mode.
Below are descriptions of the effects of having Security: ON (enabled) and
Security: OFF (disabled):
•
Security: ON – A password is required for access to the setup mode.
Whenever you pick the
Setup box, the password keyboard will appear
(see “Accessing the Setup Mode” in this chapter).
•
Security: OFF – No password is required for entry to the setup mode.
When you pick the
Setup box, the Color CVIM module goes directly to
setup mode.
Security Level accessed with Security OFF: With security OFF ,
picking the Setup box accesses the USER level of the setup mode, unless
the USER level shares a common password with one or both of the other
levels. In this case, the security level entered will be the highest level
available through the common password.
Displaying password keyboard with Security OFF: In order to display
the password entry keyboard with security
OFF , hold the tip of the light
pen down upon the Setup box until the keyboard appears (about two
seconds). If you are using a mouse, place the cursor over the Setup box,
and hold the left mouse button down until the keyboard appears.
To set Security to ON or OFF (available at ADMINISTRATOR level only):
Figure 4.3 Setting Security ON/OFF
Security box
Exit box
•
Pick Exit box on the main menu to access the Exit menu.
•
Pick the Security box to toggle the setting between ON and OFF .
Default Setting: The default setting is Security: ON .
Setting Security ON / OFF
