A–B
10
Chapter
10 – 1
Loading Color CVIM / USER-PAK Configurations
Contents
Chapter Objectives 10–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Color CVIM / USER-PAK Configurations 10–1 . . . . . . . . . . . . . . . . .
Checking Available Memory 10–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
This chapter describes the additional options for loading specific portions of
the Color CVIM / USER-PAK configurations which become available when
the USER-PAK option is installed.
With the USER-PAK option installed, several new options are available for
loading configurations. These new options allow you to load specific
portions of either an internally-stored configuration or the default
configuration (to become part of the current working configuration).
When you select either the Load Config. (Int) box or the Load Default
Config. on the Archival menu, these items are listed:
•
Menus* – Selecting this option loads only the menu modifications (text
modifications and/or deletions) defined by the ADMINISTRATOR.
•
Viewports / Serial Ports – Selecting this option loads only the serial
ports and/or viewports.
•
Inspection – Selecting this option loads the entire Color CVIM
configuration, outside of the two USER-PAK-related portions listed
above.
•
All CVIM* – Selecting this option loads the entire Color CVIM
configuration, consisting of all three portions above.
* Note: This option is available at the ADMINISTRATOR level only.
When you load a specific portion of the internal or the default configuration,
the corresponding portion of the RAM (current working) configuration is
overwritten. The remaining portions of the RAM configuration remain intact
and unaffected by the load.
The ability to load specific portions of a saved configuration enables you to
incorporate parts of a previous configuration with your current configuration.
This can save you time and effort in building a configuration.
To load a portion of the default configuration or internal configuration:
•
Pick Misc
→
Archival to access the Archival menu.
Chapter Objectives
Loading Color CVIM /
USER-PAK Configurations
