E-10 Module Configuration for PROFIBUS
The Net LED on the thermocouple/mV module should turn solid
green as should the Comm LED on the scanner. The connection
should report OK.
The master should now display:
Summary
This appendix illustrated how to configure your PROFIBUS
thermocouple/mV module with the SST PROFIBUS Configuration tool.
For more information, consult your PROFIBUS network documentation,
PROFIBUS scanner documentation and network configuration tool
documentation.
