Publication 1790-UM003A-EN-P

1-2 Overview

Thermocouple/mV Inputs and Ranges

The table below defines thermocouple types and their associated
full-scale temperature ranges. The second table lists the millivolt analog
input signal ranges that each channel will support.

Table 1.1 Thermocouple Analog Input Signal Types

Thermocouple
Type

Temperature
Range

Scaling (Counts)

Resolution

*

*

Filter set for 10 Hz

Accuracy

**

(0 to 55°C)

** Module only

B

+300 to +1800°C

+3000 to +18000

0.1°C

±4.2°C

E

-270 to +1000°C

-2700 to +10000

0.1°C

±2.5°C

J

-210 to +1200°C

-2100 to +12000

0.1°C

±2.8°C

K

-270 to +1370°C

-2700 to +13700

0.1°C

±3.3°C

R

-50 to +1768°C

-500 to +17680

0.1°C

±3.6°C

S

-50 to +1768°C

-500 to +17680

0.1°C

±3.6°C

T

-270 to 400°C

-2700 to 4000

0.1 °C

±1.3°C

N

-270 to 1300°C

-2700 to 13000

0.1°C

±3.1°C

Table 1.2 mV Analog Input Signal Types

Millivolt Input

Range

Scaling
(Counts)

Resolution

*

*

Filter set for 10 Hz

Accuracy

**

(0 to 55°C)

** Module only

10

µ

V

-76.5 to +76.5 mV

-7650 to +7650

10

µ

V

306

µ

V
