background image

Publication 1790-UM003A-EN-P

Diagnostics and Troubleshooting 4-3

Power-up Diagnostics

Power-up diagnostics includes module status and network status.

Module Status

At module power-up, a series of internal diagnostic tests are performed.
These diagnostic tests must be successfully completed. The following
table shows module status LED indictor operation.

Network Status

The network status LED indicator shows the condition of the network
connection. The following tables show network status LED indicator
operation.

Table 4.1

1790D-4T0/T4T0, 1790P-4T0

LED Indicator:

Status:

Description:

Module Status

Solid Red

Unrecoverable fault

Flashing Red

Recoverable fault

Solid Green

Normal operation - OK

Flashing Green

Standby

Off

No power

Table 4.2 1790D-4T0/T4T0 LED Descriptions

LED Indicator

Status

Description:

Network Status

Solid Red

Unrecoverable communication fault

Flashing Red

Recoverable communication fault

Solid Green

Communication path complete - OK

Flashing Green

Communication path incomplete

Off

Device not online or not powered

Table 4.3 1790P-4T0 LED Descriptions

LED Indicator

Status

Description

Network Status

Solid Green

Communication path complete - OK

Flashing Green

Communication path incomplete

Off

No power or baud rate search
