Publication 1790-UM003A-EN-P
A-4 Specifications
Thermocouple/mV
Specifications
Thermocouple/mV Specifications
Inputs per module
4 channel, Thermocouple/mV Input
Input Range ±76.50 mV
Sensors Supported Sensor Type Degree Counts
Voltage 10
µ
V -76.5 to +76.5 -7650 to +7650
B 300 to 1800°C 3000 to 18000
E -270 to +1000°C -2700 to +10000
J -210 to +1200°C -2100 to +12000
K -270 to +1370°C -2700 to +13700
R -50 to +1768°C -500 to +17680
S -50 to +1768°C -500 to +17680
T -270 to +400°C -2700 to +4000
N -270 to 1300°C -2700 to 13000
Resolution 16 bits, 0.1°C/bit or 0.1°F/bit (Thermocouple Sensors)
20bit Sigma-Delta modulation converter
Data Format 16 bit Integer (2’s compliment)
Module Scan Time 140ms/channel @ Notch Filter = 60Hz
Overall accuracy 0.2% Full scale @ 0°C-55°C
Settable Notch Filter 10Hz (default), 25Hz, 50Hz, 60Hz, 100Hz, 250Hz, 500Hz
Open Wire Detection Out of range, open wiring
Cold Junction
Compensation Range
0 to 70°C
Input Impedance 5M ohm
