Publication 1769-UM002B-EN-P - July 2005
Module Data, Status, and Channel Configuration for the Input Modules 3-11
Valid Input Data Word Formats/Ranges
The following table shows the valid formats and min./max. data ranges
provided by the module.
Table 3.7 Valid Input Data
1769-IF4 Input
Range Input Value Example
Data Input
Range
Condition Raw/Propor
tional Data Engineering
Unit Scaled-for-
PID Percent
Full Range
Decimal
Range Decimal
Range Decimal
Range Decimal
Range
-10V to +10V dc Over 10.5V dc +11.0V dc Over-range 32767 (max.) 10500 (max.) 16793 (max.) N/A
+10.5V dc + 10.5V dc Over-range 32767 (max.) 10500 (max.) 16793 (max.) N/A
-10V to +10V dc +10.0V dc Normal 31206 10000 16383 N/A
0.0V dc Normal 0 0 8192 N/A
-10.0V dc Normal -31206 -10000 0 N/A
-10.5Vdc -10.5V dc Under-range -32767 (min.) -10500 (min.) -410 (min.) N/A
Under -10.5V dc -11.0V dc Under-range -32767 (min.) -10500 (min.) -410 (min.) N/A
0V to 5V dc Over 5.25V dc 5.5V dc Over-range 32767 (max.) 5250 (max.) 17202 (max.) 10500 (max.)
5.25V dc 5.25V dc Over-range 32767 (max.) 5250 (max.) 17202 (max.) 10500 (max.)
0.0V dc to 5.0V dc 5.0V dc Normal 31206 5000 16383 10000
0.0V dc Normal 0 0 0 0
-0.5V dc -0.5V dc Under-range -3121 (min.) -500 (min.) -1638 (min.) -1000 (min.)
Under -0.5V dc -1.0V dc Under-range -3121 (min.) -500 (min.) -1638 (min.) -1000 (min.)
0V to 10V dc Over 10.5V dc 11.0V dc Over-range 32767 (max.) 10500 (max.) 17202 (max.) 10500 (max.)
+10.5V dc 10.5V dc Over-range 32767 (max.) 10500 (max.) 17202 (max.) 10500 (max.)
0.0V dc to 10.0V dc 10.0V dc Normal 31206 10000 16383 10000
0.0V dc Normal 0 0 0 0
-0.5V dc -0.5V dc Under-range -1560 (min.) -500 (min.) -819 (min.) -500 (min.)
Under -5.0V dc -1.0V dc Under-range -1560 (min.) -500 (min.) -819 (min.) -500 (min.)
4 mA to 20 mA Over 21.0 mA 22.0 mA Over-range 32767 (max.) 21000 (max.) 17407 (max.) 10625 (max.)
21.0 mA 21.0 mA Over-range 32767 (max.) 21000 (max.) 17407 (max.) 10625 (max.)
4.0 mA to 20.0 mA 20.0 mA Normal 31206 20000 16383 10000
4.0 mA Normal 6241 4000 0 0
3.2 mA 3.2 mA Under-range 4993 (min.) 3200 (min.) -819 (min.) -500 (min.)
Under 3.2 mA 0.0 mA Under-range 4993 (min.) 3200 (min.) -819 (min.) -500 (min.)
