Publication 1769-UM002B-EN-P - July 2005
5-10 Module Diagnostics and Troubleshooting
Table 5.6 1769-OF8C and -OF8V Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
No Error X000 000 0 0000 0000 No Error
General Common
Hardware Error X200 001 0 0000 0000 General hardware error; no additional information
X201 001 0 0000 0001 Power-up reset state
X216 001 0 0001 0110 Microprocessor watchdog error
X220 001 0 0010 0000 Firmware corrupt (checksum failure)
X221 001 0 0010 0001 Firmware checksum error in NVRAM (calibration data checksum
failure)
Hardware-
Specific Error X300 001 1 0000 0000 General hardware error (ASIC)
1769-OF8C and
-OF8V Specific
Configuration
Error X401 010 0 0000 0001 invalid input range selected (channel 0)
X402 010 0 0000 0010 invalid input range selected (channel 1)
X403 010 0 0000 0011 invalid input range selected (channel 2)
X404 010 0 0000 0100 invalid input range selected (channel 3)
X405 010 0 0000 0101 invalid input range selected (channel 4)
X406 010 0 0000 0110 invalid input range selected (channel 5)
X407 010 0 0000 0111 invalid input range selected (channel 6)
X408 010 0 0000 1000 invalid input range selected (channel 7)
X409 010 0 0000 1001 invalid data format selected (channel 0)
X40A 010 0 0000 1010 invalid data format selected (channel 1)
X40B 010 0 0000 1011 invalid data format selected (channel 2)
X40C 010 0 0000 1100 invalid data format selected (channel 3)
X40D 010 0 0000 1101 invalid data format selected (channel 4)
X40E 010 0 0000 1110 invalid data format selected (channel 5)
X40F 010 0 0000 1111 invalid data format selected (channel 6)
X410 010 0 0001 0000 invalid data format selected (channel 7)
X411 010 0 0001 0001 invalid fault value (channel 0)
X412 010 0 0001 0010 invalid fault value (channel 1)
X413 010 0 0001 0011 invalid fault value (channel 2)
X414 010 0 0001 0100 invalid fault value (channel 3)
X415 010 0 0001 0101 invalid fault value (channel 4)
X416 010 0 0001 0110 invalid fault value (channel 5)
X417 010 0 0001 0111 invalid fault value (channel 6)
X418 010 0 0001 1000 invalid fault value (channel 7)
X419 010 0 0001 1001 invalid idle value (channel 0)
