Module Data, Status, and Channel Configuration for the Output Modules 4-23
The configuration file is typically modified using the programming software
configuration screen. For information on configuring the module using
MicroLogix 1500 and RSLogix 500, see Appendix B; for CompactLogix and
RSLogix 5000, see Appendix C; for 1769-ADN DeviceNet Adapter and
RSNetWorx, see Appendix D.
The configuration file can also be modified through the control program, if
supported by the controller. The structure and bit settings are shown in
1769-OF8C and -OF8V Channel Configuration on page 4-24.
Word
Description
Word
Description
48
Channel 6 Configuration Word 0
56
Channel 7 Configuration Word 0
49
Channel 6 Configuration Word 1
57
Channel 7 Configuration Word 1
50
Channel 6 Fault Value Word
58
Channel 7 Fault Value Word
51
Channel 6 Program Idle Mode Word
59
Channel 7 Program Idle Mode Word
52
Channel 6 Low Clamp
60
Channel 7 Low Clamp
53
Channel 6 High Clamp
61
Channel 7 High Clamp
54
Channel 6 Ramp Rate
62
Channel 7 Ramp Rate
55
Channel 6 Spare
63
Channel 7 Spare
Table 4.11 1769-OF8C and -OF8V Word 0 and 1 Bit Descriptions
Word/
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Word 0
E
Reserved
SIU SIO
LA
ER
FM
PM
HI
PFE
Word 1
Reserved
Output Data
Format Select
Reserved
Output
Type/Range
