Publication 1769-UM002B-EN-P - July 2005
5-12 Module Diagnostics and Troubleshooting
Module Inhibit Function CompactLogix controllers support the module inhibit function. See your
controller manual for details.
Whenever the output modules are inhibited, the modules enter the program
mode and the output channel is changed to the state configured for the
program mode. Whenever the input modules are inhibited, the modules
continue to provide information about changes at its inputs to the 1769
Compact Bus Master (for example, a CompactLogix controller).
Contacting Rockwell
Automation If you need to contact Rockwell Automation for assistance, please have the
following information available when you call:
• a clear statement of the problem, including a description of what the
system is actually doing. Note the LED state; also note input and output
image words for the module.
• a list of remedies you have already tried
• processor type and firmware number (See the label on the processor.)
• hardware types in the system, including all I/O modules
• fault code if the processor is faulted
1769-OF8C and
-OF8V Specific
Configuration
Error X43B 010 0 0011 1011 configuration word 1 illegal bits set (channel 2)
X43C 010 0 0011 1100 configuration word 1 illegal bits set (channel 3)
X43D 010 0 0011 1101 configuration word 1 illegal bits set (channel 4)
X43E 010 0 0011 1110 configuration word 1 illegal bits set (channel 5)
X43F 010 0 0011 1111 configuration word 1 illegal bits set (channel 6)
X440 010 0 0100 0000 configuration word 1 illegal bits set (channel 7)
(1) X represents the “Don’t Care” digit.
Table 5.6 1769-OF8C and -OF8V Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
