Rockwell Automation Publication 1732E-UM003B-EN-E - March 2014 17
Chapter
4
Install Your Module
Overview This chapter shows you how to install and wire the 1732E ArmorBlock
EtherNet/IP Dual Port 8-Point Sequence of Events Input and Scheduled Output
Modules modules. The only tools you require are a flat or Phillips head
screwdriver and drill. This chapter includes the following topics:
Install the Module To install the module:
• Set the network address
• Mount the module
• Connect the I/O, Network, and Auxiliary cables to the module.
Set the Network Address
The I/O block ships with the rotary switches set to 999 and DHCP enabled. To
change the network address, you can do one of the following:
• adjust the node address switches on the front of the module.
• use a Dynamic Host Configuration Protocol (DHCP) server, such as
Rockwell Automation BootP/DHCP.
• retrieve the IP address from nonvolatile memory.
The I/O block reads the switches first to determine if the switches are set to a
valid number. To set the network address:
1. Remove power.
2. Remove the switch dust caps.
3. Rotate the three (3) switches on the front of the module using a small
blade screwdriver.
Topic Page
Install the Module 17
Set the Network Address 17
Mount the Module 18
Wire the Module 19
Power Connectors 20
