Rockwell Automation Publication 1732E-UM003B-EN-E - March 2014 1
Chapter
1
About ArmorBlock Modules
Overview This chapter is an overview of the ArmorBlock family of modules. You will need
to understand the concepts discussed in this chapter to configure your module
and use it in an EtherNet/IP control system. The following table guides you
where to find specific information in this chapter.
Module Features The module features include:
• use of EtherNet/IP messages encapsulated within standard TCP/UDP/IP
protocol
• common application layer with ControlNet and DeviceNet
• interfacing via Category 5 rated twisted pair cable
• half/full duplex 10 Mbit or 100 Mbit operation
• mounting on a wall or panel
• communication supported by RSLinx software
• IP address assigned via standard DHCP tools
• I/O configuration via RSLogix 5000 software
• no network scheduling required
• no routing tables required
• supports connections from multiple controllers simultaneously
Hardware/Software
Compatibility The module and the applications described in this manual are compatible with
the following firmware versions and software releases.
Contact Rockwell Automation if you need software or firmware upgrades to use
this equipment.
Topic Page
Module Features 1
Hardware/Software Compatibility 1
Use of the Common Industrial Protocol (CIP) 2
Understand the Producer/Consumer Model 2
Specify the Requested Packet Interval (RPI) 2
Product Firmware Version / Software Release
1732E-IB8M8SOER and 1732E-OB8M8SR Firmware rev. 1.1 or later
