Appendix C Data Tables
62…63
Reserved 16 bits (Must be zero)
64
Schedule[4].State (8 bit)
65
Schedule[4].SequenceNumber (8 bit)
66…67
Reserved 16 bits (Must be zero)
68
Schedule[5].State (8 bit)
69
Schedule[5].SequenceNumber (8 bit)
70…71
Reserved 16 bits (Must be zero)
72
Schedule[6].State (8 bit)
73
Schedule[6].SequenceNumber (8 bit)
74…75
Reserved 16 bits (Must be zero)
76
Schedule[7].State (8 bit)
77
Schedule[7].SequenceNumber (8 bit)
78…79
Reserved 16 bits (Must be zero)
80
Schedule[8].State (8 bit)
81
Schedule[8].SequenceNumber (8 bit)
82…83
Reserved 16 bits (Must be zero)
84
Schedule[9].State (8 bit)
85
Schedule[9].SequenceNumber (8 bit)
86…87
Reserved 16 bits (Must be zero)
88
Schedule[10].State (8 bit)
89
Schedule[10].SequenceNumber (8 bit)
90…91
Reserved 16 bits (Must be zero)
92
Schedule[11].State (8 bit)
93
Schedule[11].SequenceNumber (8 bit)
94…95
Reserved 16 bits (Must be zero)
96
Schedule[12].State (8 bit)
97
Schedule[12].SequenceNumber (8 bit)
98…99
Reserved 16 bits (Must be zero)
100
Schedule[13].State (8 bit)
101
Schedule[13].SequenceNumber (8 bit)
102…103
Reserved 16 bits (Must be zero)
104
Schedule[14].State (8 bit)
105
Schedule[14].SequenceNumber (8 bit)
106…107
Reserved 16 bits (Must be zero)
108
Schedule[15].State (8 bit)
109
Schedule[15].SequenceNumber (8 bit)
110…111
Reserved 16 bits (Must be zero)
Produced Assembly Instance 177 Data Structure
Consumed
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
