C-2 DeviceNet Objects
Class Code 0x01 – Identity
Object Class Attributes
Instance 1 Attributes: Drive Instance
Instance 2 Attributes: DeviceNet Option Instance
Common Services
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 2
3 Get Number of Instances UINT 2
6 Get Max ID Class UINT 7
7 Get Max ID Instance UINT 7
Number of Instances: 2
Attribute ID Access Rule Name Data Type Value
1 Get Vendor ID UINT 1
2 Get Device Type UINT 2
3 Get Product Code UINT See Product Codes in Appendix B
4 Get Revision
Major Revision
Minor Revision Structure of
USINT
USINT
2
1
5 Get Status WORD Bit 0 = Owned
Bit 2 = Configured
Bit 10 = Recoverable Fault
Bit 11 = Unrecoverable Fault
6 Get Serial Number UDINT Unique 32 bit number
7 Get Product Name
String Length
ASCII String Structure of
USINT
STRING
32
See Product Codes in
Appendix B
9 Get Configuration
Consistency Value UINT Checksum
Attribute ID Access Rule Name Data Type Value
1 Get Vendor ID UINT 1
2 Get Device Type UINT 12
3 Get Product Code UINT 75
4 Get Revision
Major Revision
Minor Revision Structure of
USINT
USINT
1
1
5 Get Status WORD Bit 0 = Owned
Bit 2 = Configured
Bit 10 = Recoverable Fault
Bit 11 = Unrecoverable Fault
6 Get Serial Number UDINT Unique 32 bit number
7 Get Product Name
String Length
ASCII String Structure of
USINT
STRING
29
“Bul 1329I DeviceNet Interface”
Service Code
Implemented for
Service Name Class Instance
0x05 No Yes Reset
0x0E Yes Yes Get_Attribute_Single
0x11 Yes No Find_Next_Object_Instance
