Publication 1413-UM001C-EN-P - May 2006
Add Special Functionality 57
PM_1_L23 F11:4 PM #1, L2-L3 Voltage V Read
PM_1_L31 F11:5 PM #1, L3-L1 Voltage V Read
PM_1_Freq F11:6 PM #1, Frequency Hz Read
PM_1_P1 F11:7 PM #1, L1 Real Power W Read
PM_1_P2 F11:8 PM #1, L2 Real Power W Read
PM_1_P3 F11:9 PM #1, L3 Real Power W Read
PM_1_PT F11:10 PM #1, Total Real Power W Read
PM_1_Q1 F11:11 PM #1, L1 Reactive Power VAR Read
PM_1_Q2 F11:12 PM #1, L2 Reactive Power VAR Read
PM_1_Q3 F11:13 PM #1, L3 Reactive Power VAR Read
PM_1_QT F11:14 PM #1, Total Reactive Power VAR Read
PM_1_PF1 F11:15 PM #1, L1 Power Factor Read
PM_1_PF2 F11:16 PM #1, L2 Power Factor Read
PM_1_PF3 F11:17 PM #1, L3 Power Factor Read
PM_1_PFT F11:18 PM #1, Total Power Factor Read
PM_1_%THD F11:19 PM #1, measured Total Harmonic Distortion percentage % Read
PM2 Data
PM_2_I1 F12:0 PM #2, L1 Current A Read
PM_2_I2 F12:1 PM #2, L2 Current A Read
PM_2_I3 F12:2 PM #2, L3 Current A Read
PM_2_L12 F12:3 PM #2, L1-L2 Voltage V Read
PM_2_L23 F12:4 PM #2, L2-L3 Voltage V Read
PM_2_L31 F12:5 PM #2, L3-L1 Voltage V Read
PM_2_Freq F12:6 PM #2, Frequency Hz Read
PM_2_P1 F12:7 PM #2, L1 Real Power W Read
PM_2_P2 F12:8 PM #2, L2 Real Power W Read
PM_2_P3 F12:9 PM #2, L3 Real Power W Read
PM_2_PT F12:10 PM #2, Total Real Power W Read
PM_2_Q1 F12:11 PM #2, L1 Reactive Power VAR Read
PM_2_Q2 F12:12 PM #2, L2 Reactive Power VAR Read
PM_2_Q3 F12:13 PM #2, L3 Reactive Power VAR Read
PM_2_QT F12:14 PM #2, Total Reactive Power VAR Read
PM_2_PF1 F12:15 PM #2, L1 Power Factor Read
PM_2_PF2 F12:16 PM #2, L2 Power Factor Read
PM_2_PF3 F12:17 PM #2, L3 Power Factor Read
User-defined Variables
Symbol Datapoint Description Datatype Units Access
Privilege
