Appendix A – Specifications and Accessories
A-1
Controller Specifications
Table A.1 and Table A.2 contain information that is unique to each SSC

Controller rating. Table A.3
contains information that applies to all Controller ratings.
Table A.1 – Specifications for Controllers Rated 200 – 240V Single and Three Phase Input
Controller Catalog Number
Single Phase (input) 160S-AA02 160S-AA03 160S-AA04 160S-AA08
Three Phase (input) 160-AA02 160-AA03 160-AA04 160-AA08 160-AA12
Output Ratings
3 Phase Motor Rating kW (HP) 0.37 (1/2) 0.55 (3/4) 0.75 (1) 1.5 (2) 2.2 (3)
Output Current (A) Max 2.3 3.0 4.5 8.0 12.0
Power Dissipation (Watts) 20 25 40 70 105
Input Ratings
Input Voltage, Frequency 200/240V Single Phase and Three Phase, 50/60 Hz
Operational Range (V) 180 – 265V
Input kVA 1.1 1.4 2.2 3.7 5.7
Environmental Specifications
Cooling Method Convection Cooled Fan Cooled
AC Dynamic Braking Torque
➀
With external Dynamic Brake Module (%) 300 233 200 150 115
Without external Dynamic Brake Module (%) 100 100 100 50 50
Table A.2 – Specifications for Controllers Rated 380 – 460V Three Phase Input
Controller Catalog Number
Three Phase (input) 160-BA01 160-BA02 160-BA03 160-BA04 160-BA06
Output Ratings
3 Phase Motor Rating kW (HP) 0.37 (1/2) 0.55 (3/4) 0.75 (1) 1.5 (2) 2.2 (3)
Output Current (A) Max 1.2 1.7 2.3 4.0 6.0
Power Dissipation (Watts) 25 30 40 65 80
Input Ratings
Input Voltage, Frequency 380/460V Three Phase, 50/60 Hz
Operational Range (V) 340 – 506V
Input kVA 1.1 1.6 2.2 3.7 5.7
Environmental Specifications
Cooling Method Convection Cooled Fan Cooled
AC Dynamic Braking Torque
➀
With external Dynamic Brake Module (%) 300 233 200 150 115
Without external Dynamic Brake Module (%) 100 100 100 50 50
➀ Estimated. Actual value depends on motor characteristics.
