A065 [Analog Out Sel] 0/23 1 0
A066 [Analog Out High] 0/800% 1% 100%
A067 [Accel Time 2] 0.0/600.0 Secs 0.1 Secs 20.0 Secs
A068 [Decel Time 2] 0.1/600.0 Secs 0.1 Secs 20.0 Secs
A069 [Internal Freq] 0.0/400.0 Hz 0.1 Hz 0.0 Hz (for IP66,
NEMA/UL Type
4X drives)
60.0 Hz (for
IP20 drives)
A070
A071
A072
A073
A074
A075
A076
A077
[Preset Freq 0]
(1)
[Preset Freq 1]
[Preset Freq 2]
[Preset Freq 3]
[Preset Freq 4]
[Preset Freq 5]
[Preset Freq 6]
[Preset Freq 7]
0.0/400.0 Hz 0.1 Hz 0.0 Hz
5.0 Hz
10.0 Hz
20.0 Hz
30.0 Hz
40.0 Hz
50.0 Hz
60.0 Hz
(1)
To activate [Preset Freq 0] set P038 [Speed Reference] to option 4.
A078 [Jog Frequency] 0.0/[Maximum Freq] 0.1 Hz 10.0 Hz
A079 [Jog Accel/Decel] 0.1/600.0 Secs 0.1 Secs 10.0 Secs
A080 [DC Brake Time] 0.0/99.9 Secs 0.1 Secs 0.0 Secs
A setting of 99.9 Secs = Continuous
A081 [DC Brake Level] 0.0/(Drive Amps × 1.8) 0.1 Amps Amps × 0.05
A082 [DB Resistor Sel] 0/99 0 = “Disabled”
1 = “Normal RA Res”
2 = “NoProtection”
3-99 = % of Duty Cycle
0
A083 [S Curve %] 0/100% 1% 0% (Disabled)
No. Parameter Min/Max Display/Options Default
Option Output Range Minimum Output Value
Maximum Output Value
[Analog Out High] DIP Switch Position
0 “OutFreq 0-10” 0-10V 0V = 0 Hz P035 [Maximum Freq] 0-10V
1 “OutCurr 0-10” 0-10V 0V = 0 Amps 200% Drive Rated FLA 0-10V
2 “OutVolt 0-10” 0-10V 0V = 0 Volts 120% Drive Rated Output Volts 0-10V
3 “OutPowr 0-10” 0-10V 0V = 0 kW 200% Drive Rated Power 0-10V
4 “TstData 0-10” 0-10V 0V = 0000 65535 (Hex FFFF) 0-10V
5 “OutFreq 0-20” 0-20 mA 0 mA = 0 Hz P035 [Maximum Freq] 0-20 mA
6 “OutCurr 0-20” 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA 0-20 mA
7 “OutVolt 0-20” 0-20 mA 0 mA = 0 Volts 120% Drive Rated Output Volts 0-20 mA
8 “OutPowr 0-20” 0-20 mA 0 mA = 0 kW 200% Drive Rated Power 0-20 mA
9 “TstData 0-20” 0-20 mA 0 mA = 0000 65535 (Hex FFFF) 0-20 mA
10 “OutFreq 4-20” 4-20 mA 4 mA = 0 Hz P035 [Maximum Freq] 0-20 mA
11 “OutCurr 4-20” 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA 0-20 mA
12 “OutVolt 4-20” 4-20 mA 4 mA = 0 Volts 120% Drive Rated Output Volts 0-20 mA
13 “OutPowr 4-20” 4-20 mA 4 mA = 0 kW 200% Drive Rated Power 0-20 mA
14 “TstData 4-20” 4-20 mA 4 mA = 0000 65535 (Hex FFFF) 0-20 mA
15 “OutTorq 0-10” 0-10V 0V = 0 Amps 200% Drive Rated FLA 0-10V
16 “OutTorq 0-20” 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA 0-20 mA
17 “OutTorq 4-20” 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA 0-20 mA
18 “Setpnt 0-10” 0-10V 0V = 0% 100.0% Setpoint Setting 0-10V
19 “Setpnt 0-20” 0-20 mA 0 mA = 0% 100.0% Setpoint Setting 0-20 mA
20 “Setpnt 4-20” 4-20 mA 4 mA = 0% 100.0% Setpoint Setting 0-20 mA
21 “MinFreq 0-10” 0-10V 0V = Min. Freq P035 [Maximum Freq] 0-10V
22 “MinFreq 0-20” 0-20 mA 0 mA = Min. Freq P035 [Maximum Freq] 0-20 mA
23 “MinFreq 4-20” 4-20 mA 4 mA = Min. Freq P035 [Maximum Freq] 0-20 mA
Input State
of Digital In 1
(I/O Terminal 05)
Input State
of Digital In 2
(I/O Terminal 06)
Input State
of Digital In 3
(I/O Terminal 07)
Frequency Source Accel / Decel Parameter Used (2)
0 0 0 [Preset Freq 0] [Accel Time 1] / [Decel Time 1]
1 0 0 [Preset Freq 1] [Accel Time 1] / [Decel Time 1]
0 1 0 [Preset Freq 2] [Accel Time 2] / [Decel Time 2]
1 1 0 [Preset Freq 3] [Accel Time 2] / [Decel Time 2]
0 0 1 [Preset Freq 4] [Accel Time 1] / [Decel Time 1]
1 0 1 [Preset Freq 5] [Accel Time 1] / [Decel Time 1]
0 1 1 [Preset Freq 6] [Accel Time 2] / [Decel Time 2]
1 1 1 [Preset Freq 7] [Accel Time 2] / [Decel Time 2]
(2) When a Digital Input is set to “Accel 2 & Decel 2”, and the input is active, that input overrides the settings in this table.
See the PowerFlex 40 User Manual for more information on parameters.
