A CCESSORIES AND S PARE P ARTS
PIN
Shoulder Pads 75 mm (3”), pair Logo: black/yellow black 00209
blue 01209
red 02209
yellow 03209
Logo: black/silver black 00229
Reinforcement plate with thread 7/16” 00080
thread M8 01344
thread M10 01345
Eye Bolt 7/16” x 22 mm 00040
7/16” x 38 mm 00079
M10 x 25 mm SG 35
7/16” Installation Kit for B 24.15.13 [2x SG 11 and 2x S 10] Bk 01302209
HANS ® specific Shoulder Belt Set 2”/3” black S/40013
for Profi II/III-5 and -6 blue S/40113
[5-point and T-bar 6-point] red S/40213
HANS ® specific Shoulder Belt Set 2”/3” black S/40083
for Profi II/III-6F blue S/40183
[Formula Type] red S/40283
HANS ® specific Shoulder Belt Set 2”/3” black S/40093
for Hybrid II/III blue S/40193
red S/40293
PIN
Light weight bolt-in Bracket, 20° bent for 8 mm [5/16"] bolt B 64.20.08
for 50 mm [2"] webbing for 10 mm [3/8"] bolt B 64.20.10
Light weight wrap hardware for 50 mm [2"] webbing LV 4
for 75 mm [3"] webbing LV 17
3-bar slide for 50 mm [2"] webbing LV 10.A
for 75 mm [3”] webbing LV 7
Bolt-in swivel wrap Bracket B 63 for 50 mm [2"] webbing 01326
[2ea w/ bushing/washer sets] B 40 for 75 mm [3”] webbing 01325
Twin bolt-in Bracket 20°bent; for 8 mm [5/16"] bolt 01313
[kit includes 4 each with 20°bent; for 10 mm [3/8"] bolt 01314
2 washers and 2 bolts] 45°bent; for 8 mm [5/16"] bolt 01315
45°bent; for 10 mm [3/8"] bolt 01316
Bolt-in Bracket for 75 mm [3”] webbing for 7/16", 1/2" bolts B 23 C
Installation Bracket for snap-on use
B 23 A for 10 mm, 3/8”, 7/16”, 15/32” bolts B 23 A
B 23 B for 7/16”, 1/2” bolts B 23 B
B 24.15.13 Bolt-in Bracket Kit for 50 mm and 75 mm webbing
[2ea w/ bushing/washer sets for swivelling installation]
01327
