Light Weight Wrap System [LV 4]
This light weight system assembles directly to 50 mm (2”) slot brackets
and is therefore commonly used by SCHROTH for anti-sub strap bracket
and for the “Flexi-Belt™” assembly of both, the buckle latch and the
bracket.
This system is also absolutely micro slip free.
For the light weight wrap system you need:
• Racing harness with 50 mm (2”) webbing and open strap ends
• a bracket or latch with a 50 mm (2”) strap slot
• a wrap hardware (Part No. LV 4)
W
RAPPING INSTRUCTIONS
1. Place LV 4 with its thicker bar onto the bracket/latch.
2. Run strap end through
slot at LV 4 and then
from underneath
through webbing slot at
bracket/latch. Pull
through at least 200 mm
(8”) of webbing. Fold
strap end over the wider
bar of LV 4 and back
through the gap bet-
ween bracket/latch bar
and LV 4 bar.
3. Slide strap end further
through the webbing
slot at bracket/latch
and then fold the strap
end through the slot at
LV 4.
4. Pull at the load taking strap and the bracket/latch to make sure, the
webbing is properly clamped by the wrap hardware.
5. If this is not achieved, check for proper strap routing and follow these
instructions step by step again.
6. If the protruding
webbing is significant
longer than the
minimum of 50 mm [2”],
you may fold it over
again, run it through
webbing slot of the
bracket/latch and
again back and
through the webbing
slot at LV 4.
