‎Chapter 4 PAS Application Software Configuring Summary Energy and TOU Registers
Series PM175 Powermeters 83
The available options are shown in the following table:
Parameter Options Default Description
Summary/TOU Registers
TOU Unchecked
Checked Unchecked Links tariff registers to the selected
energy source
Use Profl Unchecked
Checked Unchecked Enables automatic daily profiling for
energy usage registers (both total and
tariff registers if TOU is enabled)
Dmd Profl Unchecked
Checked Unchecked Enables automatic daily profiling for
maximum demand registers (both total
and tariff registers if TOU is enabled)
Sum Profl Unchecked
Checked Unchecked Enables daily profiling for summary
registers (total of all tariffs)
Units kWh, kvarh, kVAh,
m3, CF (cubic foot),
CCF (hundred cubic
feet)
None The register measurement units. When
a register is linked to an internal energy
source, it is set automatically. When an
external pulse source is used, the user
can select a measurement unit for the
register.
Register Source List
Source
Input None
kWh Import
kWh Export
kvarh Import
kvarh Export
kVAh,
DI1-DI2
None Links an energy source to the register
Multiplier 0.001 to 100.000 1.000 The multiplication factor for the energy
source.
Target Reg#1- Reg#8 None Defines the target billing register for the
energy source. It is set automatically.
Configuring the Daily Tariff Schedule
To configure your daily tariff schedule, select Energy/TOU
from the Meter Setup menu, and then click on the TOU Daily
Profiles tab.
