‎Chapter 3 Display Operations Menu Operations
Series PM175 Powermeters 45
Device Options
This menu allows you to change the user-configurable device
options or put the meter into energy test mode. To enter the
menu, select the “OPtS” entry from the Main menu, and then
press the ENTER button.
To select a setup option:
1. Press the SELECT button to activate the middle window.
2. Use the UP and DOWN arrow buttons to scroll to the
desired option.
To change the option:
1. Press the SELECT button to activate the lower window.
2. Use the UP and DOWN arrow buttons to select the
desired option.
3. Press ENTER to confirm your changes and to store your
new setting, or press ESC to discard changes.
To exit the menu, press ESC.
The following table lists available options.
Label Parameter Options Default Description
P.cAL Power
calculation
mode
rEAc (reactive power),
nAct (non-active
power) Reactive The method used for
calculating reactive and
apparent powers
roLL Energy roll
value
E
10.E4=10,000
10.E5=100,000
10.E6=1,000,000
10.E7=10,000,000
10.E8=100,000,000
10.E9=1,000,000,000 10.E9 The value at which
energy counters roll
over to zero
Ph.En Phase energy
option E
diS = disabled
En = enabled Disabled Enables phase energy
calculations
bAtt Backup battery
mode OFF = switched OFF
On = switched ON OFF Allows to conserve a
battery while the meter
is out of operation
tESt Energy test
mode OFF = disabled
Ac.Ei = Wh pulses
rE.Ei = varh pulses Disabled Setting this option puts
the meter into the
energy test mode
An.EP Analog
expander
option
1
nonE = disabled
0-20 = 0-20 mA
4-20 = 4-20 mA
0-1 = 0-1 mA
-1-1 = ±1 mA
Disabled Enables outputs for the
AX-8 analog expanders
through port COM2. See
“Analog Expander
Setup”
1 Do not enable the analog expander output if you do not have the
analog expander connected to the meter, otherwise it will disturb
the computer communications.
Communication Ports
These two menus allow you to configure parameters for
communication ports COM1 and COM2. To enter the menu,
select “Prt.1” for COM1 or “Prt.2” for COM2 from the main
menu, and then press the ENTER button.
OPtS
rEAc
P.cAL
