‎Chapter 4 PAS Application Software Viewing Recorded Files
Series PM175 Powermeters 123
Filtering and Sorting Events
To filter events, click on the Filter button , or click on the
report window with the right mouse button and select “Filter...”.
Check the causes of events you want to display, and then click
OK.
Event records are normally shown in the order based on the
date and time of the event appearance. To change the sorting
order, click on the Sort button
, or click on the report
window with the right mouse button and select “Sort...”, check
the desired sort order, and then click OK.
Linking to Waveforms and Data Records
If a setpoint triggers the Waveform or Data recorder and is
programmed to log setpoint events to the Event log (see
Recording Setpoint Events ), then PAS automatically
establishes links to retrieved waveforms and data records
where it finds a relationship with the event.
The event ID for which PAS finds related data is blue colored.
To check a list of the event links, click on the colored event ID.
Click on a list item to move to the waveform or data log record.
Selecting Primary and Secondary Units
Voltages and currents can be displayed in primary or
secondary units. Click on the report window with the right
mouse button, select Options, select the desired units for
voltages and currents, and then click OK.
Viewing the EN50160 Power Quality
Event Log
PQ log files are displayed in a tabular view, one event per row.
PAS loads the entire database table to a window, so that you
can scroll through the log to view its contents.
Selecting Voltage Units
Voltages can be displayed in primary or secondary units. To
change units for your reports, click with the right mouse button
on the report window, select Options, select the desired
voltage units, and then click OK.
Sorting Events
The event records are normally shown in the order based on
the date and time of the event appearance. To change the
sorting order, click on the Sort button
on the window
toolbar or click with the right mouse button on the report
window and select “Sort...”, check the desired sort order, and
then click OK.
