‎Appendix D Parameters for Monitoring and
Data Logging
152 Series PM175 Powermeters
Designat
ion
Description
I2 THD I2 Current THD
I3 THD I3 Current THD
I1 KF I1 K-Factor
I2 KF I2 K-Factor
I3 KF I3 K-Factor
I1 TDD I1 Current TDD
I2 TDD I2 Current TDD
I3 TDD I3 Current TDD
V12 V12 Voltage
V23 V23 Voltage
V31 V31 Voltage
AVR
TOTAL 1-Second Total Values
kW Total kW
kvar Total kvar
kVA Total kVA
PF Total PF
PF LAG Total PF lag
PF LEAD Total PF lead
kW IMP Total kW import
kW EXP Total kW export
kvar IMP Total kvar import
kvar EXP Total kvar export
V AVG 3-phase average L-N/L-L voltage 1
V LL AVG 3-phase average L-L voltage
I AVG 3-phase average current
AVR AUX 1-Second Auxiliary Values
In In (neutral) Current
FREQ Frequency
V UNB% Voltage unbalance
I UNB% Current unbalance
RMS
(10-min) 10-min Volts and Symmetrical
Components
V1 V1/V12 Voltage 2
V2 V2/V23 Voltage 2
V3 V3/V31 Voltage 2
V ZERO-
SEQ
Zero-sequence voltage
I ZERO-
SEQ
Zero-sequence current
V UNB% Negative-sequence voltage unbalance
I UNB% Negative-sequence current unbalance
HRM
TOT (10-
min)
10-min Total Harmonics
V1 THD V1/V12 Voltage THD 2
V2 THD V2/V23 Voltage THD 2
V3 THD V3/V31 Voltage THD 2
I1 THD I1 Current THD
I2 THD I2 Current THD
I3 THD I3 Current THD
V1 THD/I V1/V12 Interharmonic voltage THD 2
V2 THD/I V2/V23 Interharmonic voltage THD 2
V3 THD/I V3/V31 Interharmonic voltage THD 2
I1 TDD I1 Current TDD
I2 TDD I2 Current TDD
I3 TDD I3 Current TDD
PHASOR
S Phasors
V1 Mag V1/V12 Voltage magnitude 2
V2 Mag V2/V23 Voltage magnitude 2
V3 Mag V3/V31 Voltage magnitude 2
