‎Chapter 4 PAS Application Software Retrieving Log Files
120 Series PM175 Powermeters
Viewing Real-time Waveforms
The PM175 allows you to retrieve and view the real-time
waveforms from your meter.
The waveforms can be displayed in different views as
overlapped or non-overlapped waveforms, as RMS cycle-by-
cycle plot, or as a harmonic spectrum chart or table. For
information on using different waveform views, see the “PAS
Getting Started Guide”.
Retrieving Log Files
Retrieving Recorded Data
Using PAS, you can retrieve recorded events, data and
waveforms from your meters and save them to files on your
PC in the MS Access database format.
Historical data can be uploaded on demand any time you need
it, or periodically through the Upload Scheduler that can
retrieve data automatically on a predefined schedule, for
example, daily, weekly or monthly. If you do not change the
destination database location, new data will be added to the
same database so you can have long-term data profiles in one
database regardless of the upload schedule you selected.
For information on uploading files and configuring the Upload
Scheduler for your meters, see the “PAS Getting Started
Guide”.
Retrieving EN50160 Statistics Files
The EN50160 statistics files and present contents of the
EN50160 evaluation counters can be retrieved by PAS and
stored to a database for later analysis.
Using the Upload Scheduler
The PAS Upload Scheduler can automatically retrieve the
EN50160 statistics files on a daily or weekly basis depending
on the EN50160 evaluation period selected in your device.
Select the Daily or Weekly schedule for the EN50160 statistics
files when configuring the upload schedule (see “Using the
Upload Scheduler” in the “PAS Getting Started Guide”).
