‎Appendix C Setpoint Triggers and Actions
148 Series PM175 Powermeters
Display Code Designation Description
M.dAY DAY OF MONTH Day of month
hour HOURS Hours
Min MINUTES Minutes
SEc SECONDS Seconds
Event Flags
FG1.On EVENT FLAG 1 ON Event flag #1 ON
… … …
FG8.OFF EVENT FLAG 8 OFF Event flag #8 OFF
Setpoint Status
SP1.On SP 1 ON Setpoint #1 ON
… … …
SP16.On SP 16 ON Setpoint #16 ON
1 In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-to-neutral; for any
other wiring mode, they will be line-to-line voltages.
Setpoint Actions
Display Code Designation Description
none NONE None (no action)
rEL.1 OPERATE RELAY #1 Operate RO1
rEL.2 OPERATE RELAY #2 Operate RO2
rEL1.OFF RELEASE RELAY #1 Release latched RO1
rEL2.OFF RELEASE RELAY #2 Release latched RO2
ELoG EVENT LOG Log to Event Log
dLoG.1 DATA LOG #1 Log to Data Log file #1
dLoG.2 DATA LOG #2 Log to Data Log file #2
dLoG.3 DATA LOG #3 Log to Data Log file #3
dLoG.4 DATA LOG #4 Log to Data Log file #4
dLoG.5 DATA LOG #5 Log to Data Log file #5
dLoG.6 DATA LOG #6 Log to Data Log file #6
dLoG.7 DATA LOG #7 Log to Data Log file #7
dLoG.8 DATA LOG #8 Log to Data Log file #8
dLoG.9 DATA LOG #9 Log to Data Log file #9
dLoG.10 DATA LOG #10 Log to Data Log file #10
dLoG.11 DATA LOG #11 Log to Data Log file #11
dLoG.12 DATA LOG #12 Log to Data Log file #12
dLoG.13 DATA LOG #13 Log to Data Log file #13
dLoG.14 DATA LOG #14 Log to Data Log file #14
dLoG.15 DATA LOG #15 Log to Data Log file #15
dLoG.16 DATA LOG #16 Log to Data Log file #16
ULoG.1 WAVEFORM LOG #1 Log to Waveform Log file #1
ULoG.2 WAVEFORM LOG #2 Log to Waveform Log file #2
Inc.Cn.1 INC CNT #1 Increment counter #1
Inc.Cn.2 INC CNT #2 Increment counter #2
Inc.Cn.3 INC CNT #3 Increment counter #3
Inc.Cn.4 INC CNT #4 Increment counter #4
CLr.Cn.1 CLR CNT #1 Clear counter #1
CLr.Cn.2 CLR CNT #2 Clear counter #2
CLr.Cn.3 CLR CNT #3 Clear counter #3
CLr.Cn.4 CLR CNT #4 Clear counter #4
CLr.Cnt CLR ALL CNT Clear all counters
CLr.Enr CLR ENERGY Clear total and phase energy accumulators
CLr.dnd CLR ALL DMD Clear all maximum demands
CLr.P.dn CLR PWR DMD Clear power maximum demands
CLr.A.dn CLR VOLT/AMP/THD DMD Clear volt, ampere and THD maximum
demands
CLr.tEn CLR TOU ENG Clear TOU energy accumulators
CLr.tdn CLR TOU DMD Clear TOU maximum demands
CLr.LHi CLR MIN/MAX Clear Min/Max log
FLG1.On SET FLAG #1 Set event flag #1
FLG2.On SET FLAG #2 Set event flag #2
FLG3.On SET FLAG #3 Set event flag #3
FLG4.On SET FLAG #4 Set event flag #4
FLG1.OFF CLR FLAG #1 Clear event flag #1
FLG2.OFF CLR FLAG #2 Clear event flag #2
