‎Chapter 3 Display Operations Data Display
Series PM175 Powermeters 35
Pressing both the UP and DOWN arrow buttons together
returns to the first page within the current display.
The SELECT button operates once it’s released. The button
has two functions:
 When pressed briefly, it switches to programming mode.
 When pressed together with the ENTER button for more
than 5 seconds, it resets Min/Max records, maximum
demands, or energies depending on the currently displayed
page. If the meter is password protected, and a simple reset
of data from the display is not allowed, the action has no
effect.
The ENERGY button switches to the Energy display. If TOU
registers are configured in the meter, you can repeatedly press
this button to scroll through all available TOU registers. When
briefly pressed once again, it switches back to the common
measurements display
Simple Reset of Accumulated Data
When the meter is not password protected, or the simple reset
of data is allowed from the display regardless of the security
setting (see
Display Setup ), the meter allows the simple “two-
button’ reset of the Min/Max registers, maximum demands,
energies, and counters from the data display mode without
entering the reset menu:
1. Select a display page where the data
you want to reset is displayed:
Min/Max log - select a Min/Max page from the Min/Max
Display.
Ampere and volt maximum demands - select the ampere
or volt maximum demand page from the Min/Max Display.
Power maximum demands - select the power maximum
demand page from the Min/Max Display.
Total and phase energies - select a total energy, or phase
energy page from the Energy Display.
Counters – select a counter page from the Status Display
2. While holding the SELECT button, press and hold the
ENTER button for about 5 seconds. The displayed data
is reset to zero.
Common Measurements Display
Scroll through pages with the UP and DOWN arrow buttons.
Common Measurements (Main Display)
1
L
V12
V23
V31
Line-to-line volts
2
P
V1
V2
V3
Line-to-neutral volts (in configurations
with a neutral wire: 4LN3, 3LN3,
3BLN3, 4LL3, 3LL3, and 3BLL3)
3 I1
I2
I3
Amps
4 kVA/MVA
PF
kW/MW
Total VA
Total PF
Total W
5 In
Hz
kvar/Mvar
Neutral current
Frequency
Total var
